Jasco Products Company
Plug-in Smart Dimmer, Dual Outlet with Simultaneous Control
14280 (ZW3107)
Light Dimmer Switch
HW: 255
ZM5202
6.51.06
0x0063 (99)
0x5044 (20548)
0x3033 (12339)
ZC10-15080017
2015-08-18 15:05:47.4698
N/A
Enhanced 232 Slave
Always On Slave
Transform any home into a smart home with the Jasco Z-Wave Smart Lighting Control Plug-in Smart Dimmer.
Transform any home into a smart home with the Jasco Z-Wave Smart Lighting Control Plug-in Smart Dimmer. The lamp module enables wireless control of on/off and dim functions for standard incandescent table and floor lamps, as well as dimmable fluorescent, LED and CFL fixtures and more! Use the dimmer control to customize the lighting output and create the perfect ambiance for any room. The space-saving horizontal module plugs into a standard wall receptacle without blocking the second outlet or obstructing placement of furniture. The Dimmer provides two Z-Wave enabled outlets for the lamps you would like to control. Perfect for two lamps on either side of a couch, table, or bed! Take control of your home lighting with Jasco Z-Wave Smart Lighting Controls!
Product Picture
3 - LED Light
LED LightSize: 1 byte
Default: 0
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | LED Light on when Z-Wave tunred OFF (Default) |
| 1 | 1 | LED Light on when Z-Wave Turned On |
| 2 | 2 | LED Light always OFF |
7 - Dim Rate
Dim RateSize: 1 byte
Default: 1
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 99 | number of steps or levels |
| 0 | 0 |
8 - Dim Rate Adjustments (From Z-Wave Controller)
Timing of steps PLEASE NOTE: Values should be entered using their singed values only, which means for example that a configuration value of 1 byte in size must have values in the range -128 to 127. Values specified here above or below the range specified by the values size need to be converted to their 2's compliment value, or if your controller supports it, may be entered using hexadecimal notation.Size: 1 byte
Default: 3
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 255 | Timing of the steps |
| 0 | 0 |
9 - Dim rate Adjustments (When Manually Controlled)
Dim rate adjustments (when manually controlled )Size: 1 byte
Default: 1
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 99 | number of steps or levels |
| 0 | 0 |
10 - Dim Rate Adjustments (When Manually Contolled)
PLEASE NOTE: Values should be entered using their signed values only, which means for example that a configuration value of 1 byte in size must have values in the range -128 to 127. Values specified here above or below the range specified by the value's size need to be converted to their 2's compliment value, or if your controller supports it, may be entered using hexadecimal notation.Size: 1 byte
Default: 3
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 255 | Timing of the steps |
| 0 | 0 |
11 - Dim Rate Adjustments (When Receiving All-On/All-Off Command)
Size: 1 byte
Default: 1
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 99 | number of steps of levels |
| 0 | 0 |
12 - Dim Rate Adjustments (When Receiving All-On/All-Off Command)
Timing of the steps PLEASE NOTE: Values should be entered using their signed values only, which means for example that a configuration value of 1 byte in size must have values in the range -128 to 127. Values specified here above or below the range specified by the value's size need to be converted to their 2's compliment value, or if your controller supports it, may be entered using hexadecimal notation.Size: 1 byte
Default: 3
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 255 | Timing of the steps |
| 0 | 0 |
1. Follow the instructions for your Z-wave certified controller to include the device to the Z-wave network. 2. Once the controller is ready to include your smart dimmer, single press and release the manual/program button on the smart dimmer to include it in the network.
1. Follow the instructions for your Z-wave certified controller to exclude a device from the Z-wave network. 2. Once the controller is ready to Exclude your device, press and release the manual/program button on the smart dimmer to exclude it from the network.
1. If plugged in, unplug the Switch from the receptacle. 2. Press and hold the top button for at least 3 seconds while you plug the dimmer into a receptacle. Note: This should only be used in the event your network’s primary controller is missing or otherwise inoperable.
