1, Have Z-Wave controller entered the inclusion mode. 2, Press the tamper switch of the sensor three times within 1.5 seconds. 3, Device added successful.

1, Have Z-Wave controller entered the exclusion mode. 2, Press the tamper switch of the sensor three times within 1.5 seconds. 3, Node has been excluded.

Pressing the tamper switch one time within 1.5 seconds, the sensor will wake up and wait for commands from the Z-Wave Controller, then go to sleep again after 10 seconds or sleep immediately when receive wake up no more information command. By default, the sensor wake up one time per 12 hours and can be modified by wake up interval set command.

When the sensor is in Z-Wave network, press five times the tamper switch within 1.5 seconds, and do not release the switch at last press until the LED lighting, then the sensor has been set to factory default, please reset the device only when the primary controller is missing or inoperable
