Sercomm
PIR Motion Sensor
SW-PIR03N
Notification Sensor
HW: 1 FW: 1.07
ZM5101
6.51.07
0x0151 (337)
0x0101 (257)
0x0001 (1)
ZC10-16125369
2016-12-23 20:04:27.611043
N/A
Enhanced 232 Slave
Reporting Sleeping Slave
Yes
Detect human movement but prevent false alarm caused by pets.
SW-PIR03N is a high-performance, easy-to-install motion sensor provides quality detection on human movements. 1. Compact and Flat Panel Design 2. 100 Meters RF Transmission Range 3. Detection Angle up to 90 degrees FOV with 15 Meters 4. Mirror Optics Design 5. Immune to Pets Up to 85 lbs ( 38 kg) 6. Built-in Ambient Temperature Sensor 7. Battery Life 2 Years 8. Low Battery Alert 9. OTA Upgrade
1 - Configure motion trigger interval
After motion detected, ignores consequent motion events during the trigger interval to save battery power. If “Walk Test” jumper is enabled, the interval will be set to 2 seconds and ignores this configuration.Size: 2 bytes
Default: 180
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 2 | 180 | Unit: 1s |
1. Install the battery and the Pairing LED indicator will be lit for one second to indicate a successful booting. 2. It will blink one time every second while scanning the network. 3. If the network is not found after 30 seconds, the sensor will go into sleep mode. To wake the sensor again, you need to use the tamper switch to trigger the adding (Inclusion) process, and then the sensor will repeat steps from 2 to 3.
1. Set the Z-Wave controller to ""Exclusion"" mode. 2. Press the tamper button 3 times within 2 seconds. 3. The PIR LED will light up for 1 second if success. 4. The device will begin to search for a new network.
Remove the back cover to wake up SW-PIR03N.
Please reset the device to factory default only when the primary controller is missing or inoperable. 1. Press the tamper switch 4 times within 2 seconds and hold the 4th press until the PIR LED lights up. 2. The PIR LED will be off after 3 seconds and all settings will be reset to factory defaults.
| Type | Value(s) |
|---|
| Sensor type |
|---|
| Air Temperature |
