The Keyfob needs to be woken up to receive information about the new configuration from the Z-Wave controller, like parameters and associations. To wake up the device press O and + simultaneously or use 1st menu position: 1) Press O and – simultaneously. 2) Press Δ or X until LED glows white. 3) Press + to confirm.

Reset procedure allows to restore the device back to its factory settings, which means all information about the Z-Wave controller and user configuration will be deleted. There are two ways of resetting the device: • Resetting using the menu 1) Press O and – simultaneously. 2) Press Δ or X until LED glows yellow. 3) Press + to confirm. • Resetting on start-up 1) Remove the battery. 2) Hold O and + while inserting the battery. Successful resetting will be confirmed by smoothly brightening and dimming of the yellow LED colour. Please use this procedure only when the network primary controller is missing or otherwise inoperable

1) Place the KeyFob within the direct range of your Z-Wave controller. 2) Set the main Z-Wave controller in (security/non-security) add mode (see the controller’s manual). 3) Press any button three times. 4) Wait for the adding process to end. 5) Successful adding will be confirmed by the Z-Wave controller’s message and green LED colour.

1) Place the KeyFob within the direct range of your Z-Wave controller. 2) Set the main Z-Wave controller in remove mode (see the controller’s manual). 3) Press O and – simultaneously. 4) Press Δ or X until LED glows green. 5) Press + to confirm. 6) Wait for the removing process to end. 7) Successful removing will be confirmed by the Z-Wave controller’s message.
