Zipato
Indoor Siren, Multisound, Z-wave
ph-pse02.eu
Siren
HW: 1 FW: 1.15:01.12
SD3502
6.51.09
0x0131 (305)
0x0004 (4)
0x000A (10)
ZC10-17055596
2017-05-19 22:12:37.868862
N/A
Enhanced 232 Slave
Always On Slave
Zipato Indoor Siren is a wireless siren, based on Z-Wave technology.
Zipato Indoor Siren is a wireless siren, based on Z-Wave technology. It is the Z-Wave plus product, it supports the security, OTA... all the newest features of the Z-Wave technology.
Product Picture
7 - Customer Function
Customer function switch, using bit control.Size: 1 byte
Default: 0
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 16 | 16 | Notification Type, 0: Using Notification Report. 1: Using Sensor Binary Report. |
29 - Disable Alarm
Disable the alarm function. 1: Disable Alarm, 0: Enable Alarm. Caution: After the power up, this configuration always be 0.Size: 1 byte
Default: 0
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 1 | 1: Disable Alarm, 0: Enable Alarm. |
31 - Alarm Duration
Play alarm sound duration, 1 tick is 30 seconds. Default is 3 minutes, maximum is 63.5 minutes 0: means never auto stop.Size: 1 byte
Default: 6
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 127 | Play alarm sound duration, 1 tick is 30 seconds |
1. Have Z-Wave Controller entered inclusion mode. 2. Pressing tamper key three times within 1.5 seconds to enter the inclusion mode. 3. After add successful, the LED will light ON 1 second
1. Have Z-Wave Controller entered exclusion mode. 2. Pressing tamper key three times within 1.5 seconds to enter the exclusion mode. Node ID has been excluded.
Notice: Use this procedure only in the event that the primary controller is lost or otherwise inoperable. 1. Pressing tamper key four times within 1.5 seconds and do not release the tamper key in the 4 pressed, and the LED will light ON. 2. After 3 seconds the LED will turn OFF, after that within 2 seconds, release the tamper key. If successful, the LED will light ON one second. Otherwise, the LED will flash once. 3. IDs are excluded and all settings will reset to factory default.
Tamper Report When the tamper key is pressed over 5 seconds. The device will into the alarm state. In that state, if the tamper key be released, the device will unsolicited to send the report to the nodes in the group 1.
| Type | Value(s) |
|---|
| Group | Type |
|---|---|
| Home Security | (Refer to parameters): State idle |
