Zooz
Zooz Z-Wave Plus Power Switch
ZEN15
On/Off Power Switch
HW: 1 FW: 1.00
ZM5101
6.51.09
0x027A (634)
0x0101 (257)
0x000D (13)
ZC10-17075708
2017-07-10 16:22:46.104264
N/A
Enhanced 232 Slave
Always On Slave
The Zooz Power Switch is the perfect solution to control heavy duty appliances powered by 110V and rated at or below 15A / 1/2 HP.
PRODUCT FEATURES: Local and Z-Wave wireless control of your favorite home appliances like microwaves and refrigerators. Energy monitoring in live mode or over time (your Z-Wave gateway needs to support this feature). Scene inclusion for custom automation events when included to a Z-Wave gateway controller. On/Off status recovery after power failure. LED indicator to display Z-Wave signal strength and power usage for the connected device. Added security with AES signal encryption (requires a security enabled gateway controller for full functionality). Z-Wave Plus with improved 500 chip for faster and more reliable wireless communication. Built-in range extender. SPECIFICATIONS: Model Number: ZEN15 Z-Wave Signal Frequency: 908.42 MHz Power: 120V, 60Hz Maximum Load: 15A, 1800W, ½ HP Operating Temperature: 14° – 104° F Range: Up to 130 feet line of sight Installation and Use: Indoor only Dimensions: 20” (with cord) x 2.6” x 1.1” Weight: 10oz
Product Picture
20 - Overload Protection
Overload protection will turn the Power Switch relay off once power exceeds 16.5A for over 5 seconds when this setting is enabled. We DO NOT recommend changing this parameter’s value as it may result in device damage and malfunction. Values: 0 – Disabled; 1 – Enabled (default).Size: 1 byte
Default: 1
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Disabled |
| 1 | 1 | Enabled |
21 - On/Off Status Recovery After Power Failure
Choose the recovery state for your Power Switch if power outage occurs. Values: 0 – Power Switch remembers the status prior to power outage and turns back to it (default); 1 – Power Switch automatically turns ON once power is restored (it does not remember the status prior to power outage); 2 – Power Switch automatically turns OFF once power is restored (it does not remember the status prior to power outage);Size: 1 byte
Default: 0
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Power Switch remembers the status prior to power outage and turns back to it |
| 1 | 1 | Power Switch automatically turns ON once power is restored |
| 2 | 2 | Power Switch automatically turns OFF once power is restored |
24 - On/Off Status Change Notifications
Your Power Switch will automatically send a notification to the controller and other associated devices if its status changes from on to off or the other way round. Choose when you want it to send the report. Values: 0 – disabled (it will not send status change notifications); 1 – sends notification if status is changed manually or remotely via Z-Wave (default); 2 – sends notification ONLY if status is changed manually by pressing and releasing the Z-Wave button on the Power Switch;Size: 1 byte
Default: 1
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Disabled |
| 1 | 1 | Sends notification if status is changed manually or remotely via Z-Wave |
| 2 | 2 | Sends notification ONLY if status is changed manually by pressing and releasing the Z-Wave button on the Power Switch |
27 - LED Indicator Control
You can choose how the LED indicator displays power consumption on the Power Switch Values: 0 – LED indicator will display power consumption whenever the device is plugged in (LED stays on at all times – default setting); 1 – LED indicator will display the level of power consumption for 5 seconds only whenever the device is turned on or off (LED indicator will stay off for most of the time).Size: 1 byte
Default: 0
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | LED indicator will display power consumption whenever the device is plugged in |
| 1 | 1 | LED indicator will display the level of power consumption for 5 seconds only whenever the device is turned on or off |
151 - Power Report Value Threshold
Choose how you want your Power Switch to report power consumption to your controller and associated devices. The number entered as value corresponds to the number of Watts the appliance needs to go over for the change to be reported. So if 50 Watts are entered by default, the Power Switch will report any change in power usage over 50 Watts (whether it’s at least 50 Watts more or 50 Watts less compared to previous report). Values: 0 – 65535; 0 – disabled (it will not report power consumption based on value change)Size: 2 bytes
Default: 50
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 65535 | Number of Watts the appliance needs to go over for the change to be reported |
| 0 | 0 | Disabled |
152 - Power Report Percentage Threshold
Choose how you want your Power Switch to report power consumption to your controller and associated devices by percentage rate. The number entered as value corresponds to the percentage in power usage change the appliance needs to go over for the event to be reported. So if 10% is entered by default, the Power Switch will report any change in power consumption over 10% (whether it’s at least 10% more or 10% less power consumption compared to previous report). Values: 0 – 255; 0 – disabled (it will not report power consumption based on percentage change)Size: 2 bytes
Default: 10
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 255 | Percentage in power usage change the appliance needs to go over for the event to be reported |
| 0 | 0 | Disabled |
171 - Power Report Frequency
Choose how often you want your Power Switch to report power consumption (W) to your controller and associated device. The number entered as value corresponds to the number of seconds. So if 30 is entered by default, the Power Switch will report power consumption every 30 seconds. Values: 5 – 2678400; 0 – disabled (it will not report power consumption)Size: 4 bytes
Default: 30
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 5 | 2678400 | Number of seconds |
| 0 | 0 | Disabled |
172 - Energy Report Frequency
Choose how often you want your Power Switch to report energy usage (KWH) to your controller and associated device. The number entered as value corresponds to the number of seconds. So if 300 is entered by default, the Power Switch will report energy usage every 300 seconds (5 minutes). Values: 5 – 2678400; 0 – disabled (it will not report energy usage);Size: 4 bytes
Default: 300
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 5 | 2678400 | Number of seconds |
| 0 | 0 | Disabled |
173 - Voltage Report Frequency
Choose how often you want your Power Switch to report voltage (V) to your controller and associated device. The number entered as value corresponds to the number of seconds. Values: 5 – 2678400; 0 – disabled (default – it will not report voltage levels)Size: 4 bytes
Default: 0
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 5 | 2678400 | Number of seconds |
| 0 | 0 | Disabled |
174 - Electricity Report Frequency
Choose how often you want your Power Switch to report levels of electrical current (A) to your controller and associated device. The number entered as value corresponds to the number of seconds. Values: 5 – 2678400; 0 – disabled (default – it will not report electrical current levels)Size: 4 bytes
Default: 0
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 5 | 2678400 | Number of seconds |
| 0 | 0 | Disabled |
Please include the Power Switch to your network BEFORE connecting it to the appliance you wish to control. Auto Z-Wave Inclusion: 1. Put your Z-Wave controller into inclusion mode 2. Plug the Power Switch into a grounded receptacle located within direct range from your Z-Wave gateway controller 3. The LED indicator will start flashing blue, then turn blue (on) or pink (off) once included 4. A new on / off device will be recognized by your Z-Wave controller Manual Z-Wave Inclusion: 1. Plug the Power Switch into a grounded receptacle located within direct range from your Z-Wave gateway controller 2. Put your Z-Wave controller into inclusion mode 3. Press and release the Z-Wave button 3 TIMES QUICKLY 4. The LED indicator will start flashing blue, then turn blue (on) or pink (off) once included 5. A new on / off device will be recognized by your Z-Wave controller Secure Z-Wave Inclusion: 1. Plug the Power Switch into a grounded receptacle located within direct range from your Z-Wave gateway controller 2. Put your Z-Wave controller in secure inclusion mode Press and HOLD the Z-Wave button for at least 3 seconds 3. The LED indicator will start flashing green, then turn blue (on) or pink (off) once included 4. A new secure on / off device will be recognized by your Z-Wave controller
1. Plug the Power Switch into a grounded receptacle located within direct range of your Z-Wave gateway controller 2. Put your Z-Wave controller into exclusion mode 3. Press and release the Z-Wave button 3 TIMES QUICKLY 4. The LED indicator will start flashing orange, then turn blue (on) or pink (off) once excluded 5. The Power Switch will disappear from your controller's device list. The LED indicator will remain solid orange for a few seconds to indicate exclusion If the first attempt is unsuccessful, please repeat the process following all steps carefully.
When your network’s primary controller is missing or otherwise inoperable, you may need to reset the device to factory settings manually. In order to complete the process, plug the Power Switch into a grounded receptacle, then PRESS AND HOLD the Z-Wave button for AT LEAST 20 SECONDS. The LED indicator will flash orange and then stay solid orange for 2 seconds to indicate successful reset. The Power Switch will then turn off. NOTE: All previously recorded activity and custom settings will be erased from the device’s memory. You may only reset your Power Switch once it has been included to a Z-Wave network.
Controls 110 V appliances with high input surge current (power draw at start-up) such as motors, pumps, refrigerators, and window AC units (rated at or below 15 A / 0.5 HP)
| Type | Value(s) |
|---|
| Meter type |
|---|
| Electric Meter Consumption |
