For “Inclusion” in (adding to) a network: Put the Z-Wave TM Interface Controller into “inclusion” mode, and following its instruction to add the ZL7261 into your controller. To get in the “Inclusion” mode. By power up to get included for first time, press the Program switch 3 times within 3 seconds to be included.

For “Exclusion” from (removing from) a network: Set up the Z-Wave TM Interface Controller into “exclusion” mode, and following its instruction to delete the ZL7261 from your controller. Press the Program Switch 3 times within 3 seconds to be excluded.

Reset: Press the Program Switch then power on (plug-in) and hold for 5 seconds before release the switch. Only use this procedure when the primary controller is lost or otherwise inoperable. (Remark: This is to be used only in the case of primary controller being inoperable or otherwise unavailable.)

The ZL7261 also supports energy metering, and meter information can be sent by the device to a listening controller automatically. For “Meter Supported Get” : the Z-Wave TM Interface Controller sends “Meter Get” then “Scale” command that see what kind of power consumption measurement want to report back according to the scales below. Then ZL7261 will report back the energy consumption values. Scale: 0x00-kWh; 0x01-kVAh 0x02-W 0X04-V 0X05-A 0X06-Power Factor Support OTA Firmware update from controller. Please refer to your controller manual. Once OTA function success, please make sure to exclusive the device & inclusive again before use the device.
