LGU+ IoT@home
LGU+ IoT Switch
SSE-304
On/Off Power Switch
HW: 4 FW: 39.16
ZM5101
6.71.03
0x0233 (563)
0x0059 (89)
0x0001 (1)
ZC10-18096230
2018-09-14 16:13:04.876887
N/A
Enhanced 232 Slave
Always On Slave
U+ Switch enables Light ON/OFF remotely with push buttons and wireless connection(Z-Wave)
U+ Switch enables Light ON/OFF remotely with push buttons and wireless connection(Z-Wave) - It is easy to install. - Support 480(Watt) light power capacity. - Support temperature & humidity measurement. - Notification function for malfunction.
Product Picture
1 - Temperature & Humidity transmission period time.
Temperature & Humidity transmission period time. The unit is second.Size: 2 bytes
Default: 600
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 60 | 3600 | This unit is second. |
| 0 | 0 |
2 - The deviation of temperature.
The deviation of temperature. The unit is degree.Size: 1 byte
Default: 20
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 10 | 30 | The unit is degree. |
| 0 | 0 |
3 - The deviation of humidity.
The deviation of humidity. The unit is percentage.Size: 1 byte
Default: 10
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 5 | 20 | The unit is percentage. |
| 0 | 0 |
▶ Add / Remove by the button in the bottom (3rd Button) ▶ Press the 3rd button for above 5 seconds, - Then, red color LED blinks every 0.5 second 6 times. - At this time released the button during the red color LED blinking. - Then, ZWAVE Add / Remove operation is started. - Over 30 seconds, Inclusion/ Exclusion mode is stopped.
▶ Press the 3rd button for above 5 seconds, - Then, red color LED blinks every 0.5 second 6 times. - At this time released the button during the red color LED blinking. - Then, ZWAVE Add / Remove operation is started. - Over 30 seconds, Inclusion/ Exclusion mode is stopped.
1) Hold the low touch button for 10 seconds. - Keep holding the button, then at 5 second, red LED of 3rd button is blinking 6 times and keep holding10 seconds later, red LED of 3rd is blinking 6 times again. In this time factory reset will be started if you release the button. 2) After factory reset is done, all the lamps will be turned off and all variables will be initialized to default values. Please use this procedure only when the network primary controller is missing or otherwise inoperable.
This device supports temperature & humidity measurement function.
| Type | Value(s) |
|---|
| Group | Type |
|---|---|
| Power Management | (Refer to parameters): State idle |
| Sensor type |
|---|
| Air Temperature |
| Humidity |
