Auto inclusion 1. Carefully remove the front cover by pulling the bottom of the front cover. 2. Put a Z-Wave controller into inclusion mode. 3. Insert 2 AAA-batteries (1,5V) into the battery compartment with the correct polarity. The LED on the device should turn ON 4. Enter PIN number into the Z-Wave controller. The PIN number can be found on the device. See where in the installation guide. 5. The inclusion process should be completed when the LED stops blinking 6. Perform test before you refit the battery cover. See How to test the Z-Wave Device. Manual inclusion 1. Carefully remove the front cover by pulling the bottom of the front cover. There is a link button which is used to put the device in learning mode (inclusion/exclusion). 2. Press the link button 3 times within 1.5 seconds to put the unit into learning (inclusion/exclusion) mode. 3. Enter PIN number into the Z-Wave controller. The PIN number can be found on the device. See where in the installation guide. 4. The inclusion process should be completed when the LED stops blinking 5. Perform test before you refit the battery cover.

Manual exclusion 1. Detach the front cover. 2. Press the link button 3 times within 1.5 seconds to put the unit into learning (inclusion/exclusion) mode. 3. The exclusion process should be completed when the LED stops blinking. 4. Refit the front cover.

After the detector has been included into a Z-Wave network it will go to sleep, but it will send a wake-up notification command to the controller periodically at a preset period . The detector will stay awake for at least 10 seconds and then go back to sleep to conserve battery life.

1. Press the link button 3 times within 1.5 seconds to put the device into exclusion mode. 2. Within 1 second of step 1, press the link button again and hold for 5 seconds. 3. Node ID is excluded. The device reverts to factory default state. (This procedure should only be used when the controller is inoperable.)
