EVA LOGIK
Outdoor Smart Plug - 1 channel
ZW96
On/Off Power Switch
HW: 255 FW: 1.255
ZM5202
6.71.01
0x0312 (786)
0xC000 (49152)
0xC003 (49155)
ZC10-19056511
2019-05-28 23:02:22.68496
N/A
Enhanced 232 Slave
Always On Slave
The smart plug provides one Z-Wave outlet for remote controlled by controller and can be configured in Z-Wave sensor network, if Z-Wave certified controller features remote access, you can now control your device from your mobile phone devices.
The smart plug provides one Z-Wave outlet for remote controlled by controller and can be configured in Z-Wave sensor network, if Z-Wave certified controller features remote access, you can now control your device from your mobile phone devices. The outlets have maximum load for 960W Incandescent, ½ HP motor or 1800W resistive.
Product Picture
1 - LED
Status LED ConfigurationSize: 1 byte
Default: 0
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | outlet on,led on |
| 1 | 1 | outlet on ,led off |
| 2 | 2 | led no work |
2 - Timer
The countdown time, the socket closedSize: 2 bytes
Default: 0
Minimum: 0
Maximum: 0
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 36000 | The countdown time, the socket closed |
1:Refer to your primary controller instructions to process the inclusion / exclusion setup procedure. 2:When prompted by your primary controller, click the PROG button five times in one second.
1:Refer to your primary controller instructions to process the inclusion / exclusion setup procedure. 2:When prompted by your primary controller, click the PROG button five times in one second.
---Power off ZW96 ---keep holding the PROG button ---Power on,Press and keep holding the PROG button for no less than 10 seconds. Please use this procedure only when the network primary controller is missing or otherwise inoperable.
| Type | Value(s) |
|---|
| Group | Type |
|---|---|
| Heat Alarm | (Refer to parameters): State idle |
