a. Press & hold Inclusion/Exclusion button for 5 seconds when Door Sensor is exclusion status. b. LED of Door sensor will be on 5 seconds later. c. Door sensor will try Inclusion for 30sec when button is released. d. LED will blink 3 times with 250ms interval if Inclusion is successful.

a. Receiver will stay exclusion waiting mode. b. Press & hold Inclusion/Exclusion button for 5 seconds when Door Sensor is Inclusion status. c. LED of Door sensor will be on 5 seconds later. d. Door sensor will try Exclusion when button is released. e. LED will blink 3 times with 250ms interval if Exclusion is successful.

a. Device sends Wake up Notification by every 15 minutes(default). b. Devices also sends Wake up Notification when inclusion/exclusion button is shortly pressed(200ms~1sec) regardless of 15minutes interval.

a. Press & hold Inclusion/Exclusion button for 10sec. b. LED will blink while holding the button. c. Factory reset will be done in 5sec after releasing button and LED will blink 5 times with 100ms interval. * Please use this procedure only when the network primary controller is missing or otherwise inoperable.

* Configuration Parameters a. Parameter Number : Battery Period (0x01). b. Description of parameter and its effect on the product : Battery Report Period Value c. Default value : 0x18 d. Size (Number of bytes) : 1 Byte e. Possible Values : 0x01 ~ 0xFF

QR code and PIN code is located above the battery insertion position. Please refer to Section 17 of the manual
