To add a Z-Wave Device: 1. Click Pulse Devices, and then click Switches, Door Locks, Thermostats, Others. The Z-Wave Devices list screen appears. 2. Click Add. 3. Click the Z-Wave device’s “include” button. If you are adding a Z-Wave device with S2 security to an in-home gateway model number PGZNG1 v2, a dialog will prompt you for the 5-digit DSK (Device Specific Key). 4. Follow the instructions on the dialog: a. Locate the 5-digit DSK on the Z-Wave device. b. Enter the 5-digit DSK. c. For assistance in locating the DSK, click the information (i) icon on the dialog. d.Press Continue. 5. Click on the newly added Z-Wave device list item. 6. In the Name field, enter a name for the Z-Wave device, and then click Save.

To remove a Z-Wave device, click on the device in the Z-Wave Devices list to open the Z-Wave Device Details screen. Click the Remove button.

To reset the device, press and hold the reset button on the back of the unit for about 15 seconds. The unit will then restart. Note: If this controller is the primary controller for your network, resetting it will result in the nodes in your network being orphaned and it will be necessary after the reset to remove and re-add all of the nodes in the network. If this controller is being used as a secondary controller in the network, use this Copyright © 2014-2018 ICN Acquisition, LLC. All rights reserved. procedure to reset this controller only in the event that the network primary controller is missing or otherwise inoperable.

This product has a permanent waiver so that DSK is not required.

Whether you can add devices to your site depends on the type of system and service you have as well as whether you are the site owner. If you are authorized to add devices, a Manage Devices button appears on the Web Portal's System tab. If the Manage Devices button does appear on the System tab, use the following procedure to add devices. To add a device to the site: Log in to the Web Portal. Click the System tab, if it is not already displayed. Click Manage Devices. Click the type of device you want to install and follow the on-screen instructions.

If you are authorized to reset a Z-Wave device, a Manage Devices button appears on the System tab. (Resetting or deleting a Z-Wave device both result in removing the Z-Wave device from the site.) To delete or reset a Z-Wave device: Click the System tab, if it is not already displayed. Click Manage Devices. The Manage Devices page appears. Click Switches, Doors, Thermostats, Others. The Z-Wave Devices page appears. Click Reset. The Reset Z-Wave Devices page appears. Quickly press the ""include"" button on the device that you want to reset. A message informs you that the device was successfully reset, and, in addition, the Z-Wave device is removed from the site. Once reset, you can add the Z-Wave device again to the same site or add it to another site.
