Aeotec
Recessed Door Sensor 7
ZW187-C
Notification Sensor
HW: 187 FW: 1.04
ZGM130
7.12.2
0x0371 (881)
0x0002 (2)
0x00BB (187)
ZC12-20010026
2019-12-19 13:45:50.996266
N/A
Enhanced 232 Slave
Reporting Sleeping Slave
Yes
Recessed Door Sensor 7 is a wireless notification sensor product which is embedded inside the wooden door or window.
Recessed Door Sensor 7 is a wireless notification sensor product which is embedded inside the wooden door or window. This product is powered by battery and used for detecting the opening or closing of doors, windows. It can communicate with an associated Z-Wave product, such as Siren, Switch, etc. This product supports Security 2 Command Class. While a Security S2 enabled Controller is needed in order to fully use the security feature. This product can be operated in any Z-Wave network with other Z-Wave certified products from other manufacturers. All mains operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network. This product supports the Over The Air (OTA) feature for the product's firmware upgrade.

Product Image
View configuration parameters (8)
1 - Binary Sensor Report
Enable/Disable Binary Sensor Report. Allow for backward compatibility to report Binary if Notification Report cannot be use for status changes.Size: 1 byte
Default: 0
Minimum: 0
Maximum: 1
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Disable. Sensor Binary Report will NOT be issued via Lifeline when Magnet is away or near. |
| 1 | 1 | Enable. Sensor Binary Report will be issued via Lifeline when Magnet is away or near. |
2 - Sensor Reports
Reverse Sensor Reports (both Sensor Binary Report and Notification Report.)Size: 1 byte
Default: 0
Minimum: 0
Maximum: 1
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Open Status when Magnet is away, Close Status when magnet is near. |
| 1 | 1 | Close Status when Magnet is away, Open Status when magnet is near. |
3 - Association Group 2 Settings
Configure the Basic Set value. Determine the Basic Set value to control other Z-Wave devices directly when Magnet is away or near.Size: 1 byte
Default: 1
Minimum: 0
Maximum: 6
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Disable completely. |
| 1 | 1 | Send Basic Set 0xFF when Magnet is away, and send Basic Set 0x00 when Magnet is near. |
| 2 | 2 | Send Basic Set 0x00 when Magnet is away, and send Basic Set 0xFF when Magnet is near. |
| 3 | 3 | Only send Basic Set 0xFF when Magnet is away. |
| 4 | 4 | Only send Basic Set 0x00 when Magnet is near. |
| 5 | 5 | Only send Basic Set 0x00 when Magnet is away. |
| 6 | 6 | Only send Basic Set 0xFF when Magnet is near. |
4 - Application Layer Retry
Configure retry number and wait time. The device supports an application retry mechanism when the application of the device has detected a transmission error when Basic Set, Sensor Binary Report or Notification Report (Access Control) message is sent out but fails to result in an ACK or a Supervision Report.Size: 2 bytes
Default: 0
Minimum: 0
Maximum: 1535
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 1535 | The Byte 1 is used to configure the number of retries. The valid value is 0-5. 0 means disable retry. The Byte 2 is used to confiqure the wait time between retries. The valid value is 0-255. Unit is 100ms. |
5 - Supervision Report Wait Time
Configure Supervision Report Wait TimeSize: 1 byte
Default: 15
Minimum: 1
Maximum: 50
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 50 | Unit is 100ms. Note: Issuing Basic Set, Sensor Binary Report or Notification Report(Access Control) via association groups uses Supervision encapsulation only if sending commands with S2(or higher security) encapsulation. In other word, this parameter can be configured in any network, but works only in S2 (or higher security) network. |
81 - Led Indicator
Control LED Indicator. Determine whether the LED flash or not when sending Basic Set, Sensor Binary Report, Notification Report (Access Control) or Wake Up Notification.Size: 1 byte
Default: 3
Minimum: 0
Maximum: 3
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Completely disable LED. |
| 1 | 1 | LED quickly flashes only when sending Basic Set, Sensor Binary Report or Notification Report (Access Control). |
| 2 | 2 | LED activates only when sending Wake Up Notification. |
| 3 | 3 | LED quickly flashes when sending Basic Set, Sensor Binary Report or Notification Report (Access Control), and activates when sending Wake Up Notification. |
90 - Low battery threshold
Configure the low battery threshold. Induce battery report when battery level is less than or equal to threshold. Forward low battery report.Size: 1 byte
Default: 30
Minimum: 10
Maximum: 50
Possible values
| From | To | Desription |
|---|---|---|
| 10 | 50 | 10%-50%. |
101 - Timed battery report
Set how often battery is reported in minutes.Size: 2 bytes
Default: 70
Minimum: 1
Maximum: 14400
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 14400 | Set how often battery is reported in minutes. |
Operating instructions (5)
1. Press the sensor latch with a slotting screwdriver to remove the lid of the sensor. 2. Squeeze the sides of the sensor casing to alleviate pressure on the chipboard; slide the chipboard out. 3. Remove the Pull Tab to engage the pre-installed battery. The sensor’s LED will fade the color red in and out for a few seconds to indicate that it’s powered on. 4. To add the product to your automation network manually: (a) Set your main controller into its 'add product' mode. Refer to its manual if you are unsure of how to perform. (b) Single-click the Action Button; its red LED will flash for a few seconds. (c) If your controller supports S2 security, and you want to add the product into S2 Authenticated network, please scan the QR code or enter the PIN code (the underlined 5-digits of the DSK) when prompted. [IMPORTANT] QR/PIN can be found at the bottom of the product. A full DSK string can be found when you open the packaging on the Aeotec Logo Side. Please cut it out of the packaging and write some memo on its backside. Keep it in a safe place. (d) Wait for the adding process to end. (e) Confirm the adding result. Successful adding can be confirmed by your controller’s message or the LED status. If adding is successful, LED will become solid red color for 10 minutes and then off, or goes into sleep immediately if receiving the Wake Up No More Information from the controller. If its LED goes back to slow fade-in fade-out red color for 10 seconds, it indicates adding is unsuccessful. The product will auto-reset and then activate SmartStart. Repeat the above steps or contact us for further support if needed. 6. Squeeze the sides of the sensor casing lightly again and re-insert the chipboard as it was. Re-attach the lid. 7. Recessed Door Sensor 7 is now a part of your Z-Wave home control system. You can configure it and its automations via your Z-Wave system; please refer to your software's user guide for precise instructions.
1. Set your main controller into its 'remove product' mode. Refer to its manual if you are unsure of how to perform. 2. Make sure the product is powered. 3. Single-click the Action Button; its red LED will flash for a few seconds. 4. Confirm the removing result. Successful removing can be confirmed by your controller’s message or the LED status. If the removing is successful, LED will change to the default unpaired state which is slow fade-in fade-out red color. If its LED extinguish without slow fade-in fade-out red color, it indicates the removing is unsuccessful. Repeat the above steps or contact us for further support if needed.
1. Make sure the product is powered. 2. Press and hold the Action Button for at least 2s and release when the LED becomes slow pulsing red color, then Wake Up Notification is issued. 3. Wake Up destination is according to the Wake Up Interval Set. It will stay awake for 10 minutes after issuing Wake Up Notification, that is called 10-Minutes Awake Mode, however it will go into sleep immediately if receives Wake Up No More Information by the Wake Up destination. If you want to exit the 10-Minutes Awake Mode manually, please single-click the Action Button, then it will go into sleep immediately and its LED will extinguish. Note: There is another way to manually trigger Wake Up, that is repower on, but it’s not recommended for inconvenience. The Wake Up destination is according to the Wake Up Interval Set. The Wake Up period starts when the node issues a Wake Up Notification and it ends either 10 seconds after the last received/transmitted frame or at the reception of a Wake Up No More Information Command by the Wake Up destination.
If the primary controller is missing or inoperable, you may need to reset the product to factory settings. 1. Make sure the product is powered. 2. Press and hold the Action Button for at least 20s, and release when LED becomes solid red color, then Factory Reset is performed. 3. Wait for the LED indicator to be slow fade-in fade-out red LED color, which indicates the reset operation is successful. Otherwise, please try again. Contact us for further support if needed. Note: 1. This procedure should only be used when the primary controller is missing or inoperable. 2. Factory Reset will: (a) Remove the product from Z-Wave network; (b) Delete the Association setting; (c) Restore the configuration settings to the default.
QR/PIN can be found at the bottom of the product. A full DSK string can be found when you open the packaging on the Aeotec Logo Side. Please cut it out of the packaging and write some memo on its backside. Keep it in a safe place.
Documents (3)
Features (3)
| Type | Value(s) |
|---|
Supported notifications (4)
| Group | Type |
|---|---|
| Access Control |
|
| Power Management | Power status: Power has been applied |
| System | SW status: System software failure (manufacturer proprietary failure code provided) |
