ADD 1. Slide battery door open. 2. Insert batteries checking the correct orientation. 3. Press and hold the test button. Keep it held down as you slide the battery drawer closed. You may then release the button. NOTE: Use only your finger or thumb on the test button. The use of any other instrument is strictly prohibited.

REMOVE 1. Slide battery door open. 2. Remove and re-insert batteries checking the correct orientation. 3. Press and hold the test button. Keep it held down as you slide the battery drawer closed. You may then release the button. NOTE: Use only your finger or thumb on the test button. The use of any other instrument is strictly prohibited.

PROCEDURE TO MANUALLY WAKE-UP THE DEVICE To manual wake-up the device, slide the battery door open wait for ~5 seconds and then slide the battery drawer closed. Upon power-up, the device will send the wake-up notification.

RESET DEVICE If the device is powered up with the test button held down for 10+ seconds, the device will reset all Z-Wave settings and leave the network. Upon completion of the Reset operation, the LED will glow and the horn will sound for ~1 second. Please use this procedure only when the network primary controller is missing or otherwise inoperable.

DSK LOCATION ON THE PRODUCT Device Specific Key (DSK) to be available at the time an S2 device is added to a Z-Wave network. The QR code and the 5-digit DSK PIN can be found on the product nameplate which is located on the back of the product. The Full DSK string can be found on the product insert, available inside the product packaging.
