To add a device to the Z-Wave network, press the “Inclusion” button in the Android Controller Application.

To remove a device from the Z-Wave network, press the “Exclusion” button in the Android Controller Application.

To add an IoT gateway into another Z-Wave network as a secondary controller or inclusion controller, press “Learn Mode Classic” or “Learn Mode NWI” in the Settings dialog.

Press “RESET” in the Factory Default Reset dialog. This will reset the Z- Wave chip, and the gateway will show “DEVICE RESET LOCALLY NOTIFICATION” after the restart.

Press “DSK” to display the DSK.

In the event that the gateway is already the controller of the Z-Wave network, put the gateway into Inclusion Mode, and put another controller into the Learn Mode. The Replication will begin and network information will be sent to another controller. In the event that the gateway is integrated into an existing Z-Wave network, put the gateway into Learn Mode, and put the existing controller into Inclusion Mode. The Replication will begin and network information will be received from the existing controller.

Press “Add” to display the camera screen. As the camera starts, hold it over the QR code. Register the DSK when you correctly hold the camera over a QR code on the product label.

To add a device to the Z-Wave network, press the “Inclusion” button in the Android Controller Application.

To remove a device from the Z-Wave network, press the “Exclusion” button in the Android Controller Application.

When tapping the Setting button, a Settings dialog will be displayed. SmartStart > Show Provisioning List. Display the registered provisioning list (DSK and inclusion status). Press an item in the list to delete it.
