9.1: ADDING/REMOVING TO/FROM EXISTING Z-WAVE NETWORK This gateway can be added to an existing Z-Wave network only if no Z-Wave devices are added to it. 1. Start adding/removing procedure on the primary controller (according to its manual). 2. Go to [gearwheel image] > Z-Wave. 3. Under Start Learn Mode click Start 4. If you are prompted for the PIN, you will find it on the bottom of the gateway and on the box.

10: RESETTING TO FACTORY DEFAULTS 10.1: RESETTING SYSTEM TO FACTORY DEFAULTS ! Caution! The whole configuration will be removed and lost if not backed up. This feature allows you to restore the whole system to factory settings. It means the factory software version will be restored and all data from the system A and B will be deleted (users, devices, scenes etc.). If the gateway is set as Z-Wave secondary controller use this procedure only when the primary controller is missing or otherwise inoperable. 1. Open the Configuration Interface. 2. In the top right corner click user name 3. Choose Recovery Mode from the menu. 4. Confirm. 5. Wait for the system to reboot, the LED indicator will be pulsing red. 6. When the LED indicator turns solid red, refresh the browser tab. 7. Click Factory Reset under Network Status section. 8. Check “Yes, I’m sure and I know what I’m doing” checkbox. 9. Confirm. 10.2: RESETTING Z-WAVE TO FACTORY DEFAULTS Resetting the Z-Wave network removes all the Z-Wave devices from the gateway’s memory, but the other data remains unchanged. Scenes that used Z-Wave devices will not work anymore. 1. Open the Configuration Interface. 2. Go to [gearwheel image] > Z-Wave. 3. Under Reset Z-Wave click Reset. 4. Confirm.

In case you need full DSK or PIN code of the gateway you will find it on the device or on the box: Full DSK Label under device

8: REDISCOVERING Z-WAVE DEVICES Rediscovery – the process of reading the device’s capabilities after altering them. 1. Open the Configuration Interface. 2. Go to [gearwheel image] > Devices. 3. Click the device to expand it. 4. Go to Device configuration tab. 5. Under Device reconfiguration click Reconfigure device. 6. If the device is battery powered, wake it up manually or wait for next automatic wake up.

Copying information from this controller to the secondary controller 1. Start adding procedure according to chapter “Adding using Inclusion Mode” on page 7. 2. Start Learn Mode on the secondary controller (according to its manual). 3. After couple of minutes both controllers will have the same network information.

3.2: ADDING USING SMARTSTART SmartStart enabled devices can be added into a Z-Wave network by entering the Z-Wave DSK Code present on the product. The devices will be automatically added to the Z-Wave network using secure connection encrypted with Z-Wave S2 security framework. To add the device to the Z-Wave network using SmartStart: 1. Open the Configuration Interface. 2. Go to [gearwheel image] > Z-Wave > Smart Start. 3. Click Add DSK. 4. Enter the full DSK string code you have received with your device. 5. For advanced users: In Choose Security levels select which Security keys will be granted to the joining node (available: S2 Unauthenticated, S2 Authenticated, S2 Access Control, S0). 6. Leave the Only S2 classic inclusion unchecked. 7. Power the device and it will be added automatically within 10 minutes.

3.1: ADDING USING INCLUSION MODE To add the device to the Z-Wave network manually: 1. Open the Configuration Interface. 2. Go to [gearwheel image] > Devices. 3. Click ["+" image]. 4. Select Z-Wave Device. 5. There are few available settings: • NWI - Network-Wide Inclusion – enabling allows for adding devices outside the direct range of the gateway, • Add in S2 Security mode if device supports it, • Allow inclusion only in near proximity (less than 2 meters). 6. Click Start adding. 7. Follow adding procedure for the device you want to add (according to its manual). 8. If you are adding in Security S2 Authenticated and the device is not on the Provisioning List (see chapter 5 on page 10): Input the PIN code (the underlined part of the DSK) and click Send. 9. The device will be added within few minutes.

4.1: REMOVING DEVICES USING EXCLUSION MODE To remove the device from the this or other Z-Wave network: 1. Open the Configuration Interface. 2. Go to [gearwheel image] > Devices. 3. Click ["-" image]. 4. Select Z-Wave Device. 5. Follow removing procedure on the device (according to its manual).

5: MANAGING PROVISIONING LIST The Provision List is used to add Z-Wave devices using SmartStart or bootstrap classic S2 inclusion. 5.1: ADDING DEVICES TO PROVISIONING LIST 1. Open the Configuration Interface. 2. Go to [gearwheel image] > Z-Wave > Smart Start. 3. Click Add DSK. 4. Enter the full DSK string code you have received with your device. 5. For advanced users: In Choose Security levels select which Security keys will be granted to the joining node (available: S2 Unauthenticated, S2 Authenticated, S2 Access Control, S0). 6. If the device should not be automatically included when powered, but only after the classic inclusion, check the Only S2 classic inclusion setting. 7. Click Add. 5.2: EDITING DEVICES IN PROVISIONING LIST 1. Open the Configuration Interface. 2. Go to [gearwheel image] > Z-Wave > Smart Start. 3. Click [pen image] next to the device you want to edit. 4. You can change the Security levels. 5. Save. 5.3: REMOVING DEVICES FROM PROVISIONING LIST 1. Open the Configuration Interface. 2. Go to [gearwheel image] > Z-Wave > Smart Start. 3. Click [trash can image] next to the device you want to remove. 4. Click Delete. 5. The device will be removed from the list, but if it was already added to the Z-Wave network, you must perform standard removing procedure or reset the device.
