Zooz
Water Sensor
ZSE42
Notification Sensor
HW: 1 FW: 1.00
ZGM130
7.13.9
0x027A (634)
0x7000 (28672)
0xE002 (57346)
ZC12-21080294
2021-08-11 13:48:32.045947
N/A
Enhanced 232 Slave
Reporting Sleeping Slave
Yes
The 700 Series Z-Wave Plus™ XS Water Leak Sensor was designed to detect and report leaks to your Z-Wave™ hub reliably and quickly so you can prevent potential water damage.
PRODUCT HIGHLIGHTS: - Quick and reliable water leak alerts sent to your Z-Wave™ hub - NEW 700 series chip for faster communication and more battery life than ever - Extra small to fit anywhere - Powered by a long-lasting single coin battery - The latest S2 security and SmartStart for secure set-up - Supports OTA firmware updates PRODUCT SPECS: - Model Number: ZSE42 - Power: 1 x CR2032 battery - Operating Temperature: 32° – 104° F - Dimensions: 1.9” x 1” x 0.3” - Range: Up to 130 feet line of sight - Installation and Use: Indoor or outdoor under eve (can’t be exposed to direct rainfall or sun, a little splash is OK)
Product Image
1 - LED Indicator Mode
Choose whether you'd like the LED indicator to light up when water is detected.Size: 1 byte
Default: 1
Minimum: 0
Maximum: 1
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | LED indicator doesn't light up when water is detected |
| 1 | 1 | LED indicator lights up when water is detected |
2 - Alarm Clear Delay
Set the delay for a "dry" report to be sent to the hub when water is no longer detected.Size: 4 bytes
Default: 0
Minimum: 0
Maximum: 3600
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 3600 | seconds |
3 - Battery Reporting Threshold
Set the battery reporting threshold.Size: 1 byte
Default: 10
Minimum: 1
Maximum: 50
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 50 | % |
4 - Low Battery Alert
Set the battery level for a low battery alert to be sent to the hub.Size: 1 byte
Default: 20
Minimum: 10
Maximum: 50
Possible values
| From | To | Desription |
|---|---|---|
| 10 | 50 | % |
5 - Group 2 ON/OFF Basic Set Commands
Choose when you'd like the sensor to send on/off basic set commands to Group 2 once the water detection status changes.Size: 1 byte
Default: 1
Minimum: 0
Maximum: 2
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Doesn't send basic set commands |
| 1 | 1 | Sends 0xFF (ON) when water is detected and 0x00 (OFF) when water is no longer detected |
| 2 | 2 | Sends 0x00 (OFF) when water is detected and 0xFF (ON) when water is no longer detected |
Initiate inclusion (pairing) in the app (or web interface). Not sure how? [email protected] While the hub is looking for new devices, click the Z-Wave button 3 times as quickly as possible. The LED indicator will start flashing to confirm inclusion mode and turn off once inclusion is completed.
1. Bring the sensor within direct range of your Z-Wave hub. 2. Put the Z-Wave hub into exclusion mode (not sure how to do that? [email protected]). 3. Click the Z-Wave button 3 times as quickly as possible. 4. Your hub will confirm exclusion and the sensor will disappear from your controller's device list.
The sensor’s wake-up interval is set to 12 hours by default to save battery life. Use the Wake Up Command Class to adjust the interval. Click the Z-Wave button 4 times quickly to wake the sensor up manually. The LED indicator will flash twice to confirm the device is awake. During wake-up, the sensor turns the Z-Wave radio on for one minute to receive communication from the hub. Long wake-up interval will not affect how often the sensor reports to your hub so we recommend leaving the default setting to conserve battery.
When your network’s primary controller is missing or otherwise inoperable, you may need to reset the device to factory settings manually. In order to complete the process, make sure the sensor is powered, then click the Z-Wave button twice and hold it the third time for 10 seconds. The LED indicator will blink continuously. Immediately after, click the Z-Wave button twice more to finalize the reset. The LED indicator will flash 3 times to confirm a successful reset.
Initiate inclusion (pairing) in the app (or web interface). Not sure how? [email protected] If you’re using an S2 hub, it will ask you to enter the DSK PIN or scan the QR code printed on the back cover sticker of the sensor to complete SmartStart inclusion.
| Type | Value(s) |
|---|
| Group | Type |
|---|---|
| Water Alarm |
|
