Viewqwest Vesta
Vesta Shield
SVHSZWB1
Gateway
HW: 1 FW: 1.02:07.13:02.03
ZM5101
6.82.01
0x0367 (871)
0x0001 (1)
0x0001 (1)
ZC10-21097053
2021-09-22 12:27:51.986931
N/A
Bridge Controller
Central Static Controller
Yes
Vesta is a round the clock smart monitoring solution to protect the people and things that matter the most and help you live life at home or manage your business, better.
Vesta is a smart monitoring solution comprising of the Vesta Hub, wireless sensors and a smart plug. Vesta Hub seamlessly connects with the sensors to provide wholesome security experience and peace of mind. Current Vesta ecosystem can monitor home intrusion, room temperature & illuminance level. All the events and notifications are viewed via the Vesta mobile app (Both Android and iOS). Also, the App could notify emergency contacts about the unmonitored events and even make calls notifying on critical alerts which are triggered by the sensors.
Product Image
Steps for Performing Classic device inclusion: Step 1: Have the device to be added ready and ensure it has been reset Step 2: Go to MENU --> DEVICE SETUP --> ADD DEVICE Step 3: Press SCAN button Step 4: Press the Action button on the device to be added Step 5: Enter Partial DSK String if adding on S2 Secure mode and Submit Step 6: For S0 and Unsecure devices press the ACTION button and add without DSK Step 7: Choose the device from the list of Available Devices and Click ADD. The device is added and can be renamed
Steps for performing Classic device exclusion: Step 1: Go to MENU --> DEVICE SETUP --> REMOVE DEVICE Step 2: Click CONFIRM on the pop up message Step 3: Make sure you have the device with you and press the REMOVE button and then immediately press the action button on your device Step 4: The device will be removed from the Z-Wave network and from Vesta. This may take up to 60 secs. Once the device is removed it will no longer be visible in the device list.
Factory Reset: Please use this procedure only when the network primary controller is missing or otherwise inoperable. Factory reset can be performed in 2 ways: 1] Hardware Factory Reset: To reset the hub back to its factory default state, press the reset button (next to power cycle button) continuously for up to 5 seconds. You will hear a voice prompt to say the factory reset process has started. Then please allow up to 5 minutes for the whole reset process to complete. Once the hub has been reset, you will be notified by another voice prompt at the end to indicate that the reset process has been completed. 2] Factory Reset through App: Step 1: Go to MENU --> SETTINGS --> FACTORY RESET Step 2: Press PROCEED in the reset confirmtion dialog box Step 3: Wait for 4 minutes for the reset process to be completed
1] The security 2 DSK of the Vesta Hub comes with the product packaging as a card which is kept with the user manual. 2] Steps to Access DSK via the APP UI: Step 1: Go to the Menu Step 2: Choose Settings Step 3: Choose Show HUB DSK
| Type | Value(s) |
|---|
