Nice
Flood-Control
FGFS-101
Notification Sensor
HW: 1 FW: 3.04:03.04
ZM5202
6.51.07
0x010F (271)
0x0B01 (2817)
0x1003 (4099)
ZC10-22047081
2022-04-01 13:50:02.672135
N/A
Enhanced 232 Slave
Always On Slave
Flood-Control is a universal, Z-Wave Plus™ compatible flood and temperature sensor. The device can be powered using the battery, 12/24V DC power supply, or both. A flood alarm is sent to the Z-Wave™ network devices or additionally to any external system through opening an NC contact using the external power supply.
Flood-Control is a universal, Z-Wave Plus™ compatible flood and temperature sensor. The device can be powered using the battery, 12/24V DC power supply, or both. A flood alarm is sent to the Z-Wave™ network devices or additionally to any external system through opening an NC contact using the external power supply. The device has built in temperature sensor that allows to monitor ambient temperature. Flood-Control is designed to be placed on the floor or mounted on a wall (in this case Flood-Control probes should be extended using addition wire). The device has a built-in visual LED indicator and an acoustic alarm. In addition, the sensor is equipped with a tilt sensor reporting tilt or movement to the main controller e.g. when someone has taken the Sensor from its original location. Flood-Control is sink-proof, which means it drifts on the water surface and keeps on sending alarm signal in case of substantial inundation of water.
Product Image
1 - Alarm cancellation delay
Determines time period (in seconds) by which a Flood-Control will retain the flood state after the flooding itself has ceased. The sensor will keep on reporting flooding to the main controller. This parameter setting does not affect acoustic and visual alarms, which turn off immediately after flooding ceases.Size: 2 bytes
Default: 0
Minimum: 0
Maximum: 3600
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 3600 | Alarm cancellation delay |
2 - Acoustic and visual signals On / Off in case of flooding
The parameter allows for the deactivation of visual and acoustic alarms. The parameter allows for increasing battery life. Setting changes will not affect the sensor’s communication with the main controller - the device will still send commands to association groups, alarms, and reports.Size: 1 byte
Default: 3
Minimum: 0
Maximum: 3
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 3 | Acoustic and visual signals On / Off in case of flooding |
3 - Requested dimming level / roller blind opening level when sending turn on / open command to 2nd association group devices
Determines the requested “on” level to be sent to devices from 2nd association group upon flood event.Size: 2 bytes
Default: 255
Minimum: 1
Maximum: 255
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 255 | Requested dimming level / roller blind opening level when sending turn on / open command to 2nd association group devices |
4 - Deactivate turning off devices in 2nd association group & alarm cancellation in 3rd group
This setting decides whether device turn off commands and alarm cancellation notifications will be sent to devices in 2nd and 3rd association groups (respectively) Setting the parameter’s value to 0 disables sending these two commands to associated devices. This means that these devices WILL NOT be informed when the flooding has ceased. It is still possible to cancel alarms in 3rd association group by choosing second (green) menu position (see section 8.2 - Visual indications)Size: 1 byte
Default: 1
Minimum: 0
Maximum: 1
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 1 | Deactivate turning off devices in 2nd association group & alarm cancellation in 3rd group |
5 - Temperature measurement interval
Time interval (in seconds) between consecutive measurements of battery level and temperature (done by built-in temperature sensor). If the temperature differs from previously reported by a value determined in parameter 12, it will be reported to the Z-Wave controller. In battery mode more significant battery level changes will be reported. Short time intervals mean more frequent communication, which results in shortened battery life. After consecutive FAILED and SUCCESSFUL communication attempts, the Sensor will go to standby mode.Size: 4 bytes
Default: 300
Minimum: 1
Maximum: 65535
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 65535 | Temperature measurement interval |
6 - Temperature measurement hysteresis
Determines a minimum temperature change value (insensitivity level), resulting in a temperature report being sent to the main controller, according to the parameter 10 settings.Size: 2 bytes
Default: 50
Minimum: 1
Maximum: 1000
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 1000 | Temperature measurement hysteresis |
7 - Low temperature alarm threshold
The parameter stores a temperature value, below which visual indicator blinks with a colour determined by a parameter 61 settings. By default the visual indicator blinks blue.Size: 2 bytes
Default: 1500
Minimum: -10000
Maximum: 10000
Possible values
| From | To | Desription |
|---|---|---|
| -10000 | 10000 | Low temperature alarm threshold |
8 - High temperature alarm threshold
The parameter stores a temperature value, above which visual indicator blinks with a colour determined by the parameter 62 settings. By default the visual indicator blinks red.Size: 2 bytes
Default: 3500
Minimum: -10000
Maximum: 10000
Possible values
| From | To | Desription |
|---|---|---|
| -10000 | 10000 | High temperature alarm threshold |
9 - Low temperature alarm indicator colour
Parameter stores RGB colour value (see Table A3 for details).Size: 4 bytes
Default: 255
Minimum: 0
Maximum: 16777215
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 16777215 | Low temperature alarm indicator colour |
10 - High temperature alarm indicator colour
Parameter stores RGB colour value (see Table A3 for details).Size: 4 bytes
Default: 16711680
Minimum: 0
Maximum: 16777215
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 16777215 | High temperature alarm indicator colour |
11 - Temperature indication using LED visual indicator
Parameter determines visual indicator’s operation. Setting to 0 turns the temperature LED indication off, saving battery life.Size: 1 byte
Default: 2
Minimum: 0
Maximum: 2
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 2 | Temperature indication using LED visual indicator |
12 - Temperature measurement compensation
Parameter stores a temperature value to be added to or deducted from the current temperature measured by internal temperature sensor in order to compensate the difference between air temperature and temperature at the floor level.Size: 2 bytes
Default: 0
Minimum: -10000
Maximum: 10000
Possible values
| From | To | Desription |
|---|---|---|
| -10000 | 10000 | Temperature measurement compensation |
13 - Alarm frame sent to 1st and 4th Association Group activation (MOVEMENT_TAMPER / BUTTON_TAMPER)
The device is able to report tamper alarms resulting from sensor’s tilt/movement or TMP button state change (e.g. taking off the top cover).Size: 1 byte
Default: 2
Minimum: 0
Maximum: 3
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 3 | Alarm frame sent to 1st and 4th Association Group activation |
14 - Alarms signalization duration
The device is capable of automatically turning off alarm signalization after a certain amount of time. Long lasting alarm may reduce battery life, when constantly signalized. The parameter determines time after which alarm will become “quiet” - still active but the device will go into battery saving mode. Visual or acoustic alarm will be reactivated after time specified in the parameter 76. When alarm status ceases, alarm will be turned off immediately.Size: 4 bytes
Default: 0
Minimum: 0
Maximum: 65535
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 65535 | Alarms signalization duration |
15 - Alarm signalization reactivation period
Parameter determines a time period after which an alarm will be turned back on (in case it was turned off by parameter 75 setting). It will also resend commands to 2nd and 3rd association groups as if the alarm was detected again.Size: 4 bytes
Default: 0
Minimum: 0
Maximum: 65535
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 65535 | Alarm signalization reactivation period |
16 - Flood sensor functionality turned off
Allows to turn off the internal flood sensor. Tamper and built in temperature sensor will remain active.Size: 1 byte
Default: 0
Minimum: 0
Maximum: 1
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 1 | Flood sensor functionality turned off |
17 - Associations in Z-Wave network security mode
This parameter defines how commands are sent in specified association groups: as secure or non-secure. Parameter is active only in Z-Wave network security mode. It does not apply to 1st “Lifeline “group.Size: 1 byte
Default: 7
Minimum: 0
Maximum: 7
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 7 | Associations in Z-Wave network security mode |
Adding (Inclusion) - Z-Wave device learning mode, allowing to add the device to existing Z-Wave network. To add the device to the Z-Wave network manually: 1. Open the cover. 2. Place the Sensor within the direct range of your Z-Wave controller. 3. Set the main controller in (security/non-security) add mode (see the controller’s manual). 4. Quickly, three times press the TMP button. 5. Wait for the adding process to end. 6. Successful adding will be confirmed by the Z-Wave controller’s message.
To remove the device from the Z-Wave network: 1. Open the cover. 2. Place the Sensor within the direct range of your Z-Wave controller. 3. Set the main controller into remove mode (see the controller’s manual). 4. Quickly, three times press the TMP button. 5. Wait for the removing process to end. 6. Successful removing will be confirmed by the Z-Wave controller’s message.
Waking up the Flood-Control When in battery mode the Flood-Control needs to be woken up to receive information about the new configuration from the controller, like parameters and associations. To wake up the sensor manually, click the TMP button located inside the housing. The device will also wake up and update its data upon startup when added in battery mode.
Reset procedure allows to restore the device back to its factory settings, which means all information about the Z-Wave controller and user configuration will be deleted. 1. Make sure the sensor is powered. 2. Press and hold the TMP button. 3. Wait for the visual LED indicator to glow yellow (4th position of the MENU). 4. Release the TMP button. 5. Click the TMP button once to confirm selection. 6. After few seconds the device will restart with factory settings, which is signalled with the red visual indicator colour and 7. an acoustic signal.
| Group | Type |
|---|---|
| Water Alarm | Sensor status: Water leak detected |
| Home Security | Cover status: Tampering, product cover removed |
| Sensor type |
|---|
| Air Temperature |
