Include the TRV into the Z-Wave network manually: a. Power on your TRV, b. Set your Z-Wave controller into add/inclusion mode. c. In “OF” state, short press rotary plate three times until the screen shows “- -”. d. The screen will show “PA” after few seconds, which meant the inclusion is successful. And the signal icon will light on. Otherwise, the inclusion is failed, which you will need to repeat the process form step b.

Exclude TRV from a Z-Wave network: a. Power on your TRV b. Set the Z-Wave primary controller into remove/exclusion mode. c. In “OF” state, short press rotary plate three times until the screen shows “- -”. d. The screen will turn back to “OF” after few seconds, which meant the inclusion is successful. The signal icon light will be off. Otherwise, the exclusion is failed which you will need to repeat the process form step b.

4.3 Reset TRV to factory default In “ OF” state, press and hold rotary plate for at least 5 seconds and release when the 8 screen will blink “OF”. When the reset is successful, the screen will show “OF” in solid for 2 seconds then turn off. And TRV will reset itself to factory default by sending a “Device Reset Locally Notification” to gateway. Note: Please use this procedure only when the network primary controller is missing or otherwise inoperable.

Refer to page 7 in English End User Manuals
