Yale
Yale nexTouch Exit Trim Touch Screen Commercial Grade Lock
NTT622-ZW3
Lock DT
N/A
N/A
N/A
0x0129 (297)
N/A
0x8102 (33026)
ZC14-23050264
2023-05-24 14:15:17
N/A
Enhanced End Node 232
Listening Sleeping Slave
Never worry about carrying around or losing your keys again. Unlock and lock your home with ease from the backlit touchscreen keypad.
1 - Volume
Set Volume Level to high (1), low (2), or silent (3).Size: 1 byte
Default: 1
Minimum: 1
Maximum: 3
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
2 - Auto Relock
Set Auto Relock feature to enable or disable.Size: 1 byte
Default: 255
Minimum: 0
Maximum: 255
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
3 - Relock time
Adjust the time your lock will auto relock.Size: 1 byte
Default: 3
Minimum: 1
Maximum: 180
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
4 - Wrong Code Entry Limit
Adjust the limit for wrong code entries allowed by your lock.Size: 1 byte
Default: 5
Minimum: 3
Maximum: 10
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
5 - Language
Set the language to English (1), Spanish (2), or French (3).Size: 1 byte
Default: 1
Minimum: 1
Maximum: 3
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
7 - Shut down time
Adjust the time your lock is shutdown after reaching its wrong code entry limit.Size: 1 byte
Default: 60
Minimum: 10
Maximum: 180
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
8 - Operating mode
Set the Operating Mode to normal mode, vacation mode, privacy mode or passage mode.Size: 1 byte
Default: 0
Minimum: 0
Maximum: 3
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
11 - One Touch Locking
Set One Touch Locking feature to enable or disable.Size: 1 byte
Default: 255
Minimum: 0
Maximum: 255
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
12 - Privacy Button
Set Privacy Button feature to enable or disable.Size: 1 byte
Default: 0
Minimum: 0
Maximum: 255
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
13 - Lock Status LED
Set Lock Status LED feature to enable or disable.Size: 1 byte
Default: 0
Minimum: 0
Maximum: 255
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
18 - Door Propped Timer
Adjust the time to receive an alert when the door is propped open.Size: 1 byte
Default: 0
Minimum: 0
Maximum: 254
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
19 - DPS Alarms
Enable or Disable DPS AlarmsSize: 1 byte
Default: 0
Minimum: 0
Maximum: 255
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
28 - Expiring Pin Code Enabled Time
Timeout value used to determine time after first entry is triggered.Size: 1 byte
Default: 0
Minimum: 0
Maximum: 255
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | 0 |
1. Install the Yale Smart Module into the slot above the battery compartment IMPORTANT: The batteries must be removed before removing the Yale Smart Module: • Remove battery cover • Remove batteries • Insert or remove Yale Smart Module • Reinstall batteries • Reinstall battery cover 2. Open the Z-Wave system''s smart home or alarm app on your smartphone or tablet 3. Follow the in-app instructions for adding a new device 4. On your lock keypad, enter your master entry code followed by the gear icon 5. Press the 7 key followed by the gear icon 6. Press the 1 key followed by the gear icon
1. On your lock keypad, enter your master entry code followed by the gear icon 2. Press the 7 key followed by the gear icon 3. Press the 3 key followed by the gear icon 4. Open the Z-Wave system''s smart home or alarm app and follow the instructions for removing a device 5. Remove the Yale Smart Module from the slot above the battery compartment IMPORTANT: The batteries must be removed before removing the Yale Smart Module: • Remove battery cover • Remove batteries • Insert or remove Yale Smart Module • Reinstall batteries • Reinstall battery cover 6. If you''re adding a new Yale Smart Module, follow the instructions included with it
press any key
When lock is reset to factory defaults all Entry Codes (including the Master Entry Code*) are deleted and all programming features are reset to original default settings (see below). 1. Remove battery cover and batteries. 2. Remove inside lock to access reset button. 3. Reset button (see image at right) is located beside cable adapter. 4. While pressing reset button reinstall batteries. Hold reset button a minimum of 3 seconds then release. 5. Replace battery cover. After reset, Master Entry Code creation is the only option available and must be performed prior to any other programming of the lock
1. Install the Yale Smart Module into the slot above the battery compartment IMPORTANT: The batteries must be removed before removing the Yale Smart Module: • Remove battery cover • Remove batteries • Insert or remove Yale Smart Module • Reinstall batteries • Reinstall battery cover 2. Open the Z-Wave system''s smart home or alarm app on your smartphone or tablet 3. Follow the in-app instructions for adding a new device 4. On your lock keypad, enter your master entry code followed by the gear icon 5. Press the 7 key followed by the gear icon 6. Press the 1 key followed by the gear icon
| Type | Value(s) |
|---|
| Group | Type |
|---|---|
| Access Control |
|
| Power Management |
|
