ZOOZ
0-10V Dimmer
ZEN54 LR
Multilevel Switch DT
HW: 01 FW: 01.12
ZGM130S037HGN2 / ZGM130S037HGN1
7.16.3
0x027A (634)
N/A
0x0904 (2308)
ZC14-23090325
2023-09-04 15:08:07
N/A
Enhanced End Node 232
Always On Slave
Z-Wave™ Long Range low voltage dimmer for 0-10 V LED drivers.
1 - Restores state after power failure
The state the Dimmer should return to once power is restored after power failure.Size: 1 byte
Default: 100
Minimum: 0
Maximum: 100
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | off |
| 1 | 99 | power level is 1~99% |
| 100 | 100 | output the state after power |
2 - Led indicator load status
Led indicator load status.Size: 1 byte
Default: 1
Minimum: 0
Maximum: 1
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Disable |
| 1 | 1 | Enable |
3 - Dimming speed time
Set the speed time for Dimmer.Size: 2 bytes
Default: 3
Minimum: 0
Maximum: 100
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 100 | seconds |
4 - Minimum dim level
Lowest moving level of the Dimmer.Size: 1 byte
Default: 1
Minimum: 1
Maximum: 45
Possible values
| From | To | Desription |
|---|---|---|
| 1 | 45 | percent |
5 - Maximum dim level
Highest dimming level of the Dimmer.Size: 1 byte
Default: 99
Minimum: 55
Maximum: 99
Possible values
| From | To | Desription |
|---|---|---|
| 55 | 99 | percent |
6 - Kick start level
This feature ensures lamp start-up even at low dim levels.Size: 0 byte
Default: 0
Minimum: 0
Maximum: 99
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Disable |
| 1 | 99 | percent |
7 - Enable External Switch Pair
Enable External Switch PairSize: 1 byte
Default: 1
Minimum: 0
Maximum: 1
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | disable |
| 1 | 1 | enable |
8 - Auto turn-off timer
Automatically turns the Dimmer off after this many minutes.Size: 4 bytes
Default: 0
Minimum: 0
Maximum: 4294967295
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Disabled |
| 1 | 4294967295 | seconds |
9 - Auto turn-on timer
Automatically turns the Dimmer on after this many minutes.Size: 4 bytes
Default: 0
Minimum: 0
Maximum: 4294967295
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Disabled |
| 1 | 4294967295 | seconds |
10 - Auto turn-on/off timer units
Timer for auto up seconds or minutesSize: 1 byte
Default: 0
Minimum: 0
Maximum: 1
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | seconds |
| 1 | 1 | minutes |
11 - Enable or Disable Output control
Enable or Disable Output control (disable LOAD ONLY, ON/OFF works) relay 1.Size: 1 byte
Default: 1
Minimum: 0
Maximum: 2
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Disable local button and External Switch control enable Z-Wave control (reports on hub ON/OFF) |
| 1 | 1 | Enable local button and External Switch control enable Z-Wave control |
| 2 | 2 | Disable local button and External Switch control disable Z-Wave control (reports on hub ON/OFF ) |
12 - External switch type
External switch typeSize: 1 byte
Default: 2
Minimum: 0
Maximum: 3
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Momentary switch |
| 1 | 1 | Switch ON ->always ON. Switch OFF->always OFF |
| 2 | 2 | 3-way impulse control |
13 - Association reports
Association reportsSize: 1 byte
Default: 1
Minimum: 0
Maximum: 1
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Z-Wave control: Switch Multilevel Report Manual control: Basic report |
| 1 | 1 | Z-Wave control: Switch Multilevel Report Manual control: Switch Multilevel Report |
14 - Enable cut the power
To set cut the power when turn 0-10 dimmer to 0.Size: 1 byte
Default: 1
Minimum: 0
Maximum: 1
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Keep the power ON when turn 0-10 dimmer to 0 |
| 1 | 1 | Cut the power when turn 0-10 dimmer to 0 |
1. ADD DEVICE to your hub: Initiate inclusion (pairing) in the app (or web interface). Check Long Range if using. Not sure how? Scan one of the QR codes below for step-by-step instructions or get in touch: www.support.getzooz.com 2. Finalize inclusion at the dimmer. Tap the Z-Wave™ button 3 times quickly if using traditional Z-Wave™ inclusion. The LED indicator will blink green to signal communication and turn green for 2 seconds if inclusion is successful or turn red for 2 seconds if the pairing attempt fails.
1. Bring your Z-Wave™ hub close to the device if possible 2. Put the Z-Wave hub into exclusion mode (not sure how to do that? [email protected]) 3. Click the Z-Wave button on the relay 3 times quickly (the LED indicator will start blinking green) 4. Your hub will confirm exclusion, the LED indicator on the device will turn green for 2 seconds, and the ZEN54 will disappear from your controller''s device list.
If your primary controller is missing or inoperable, you may need to reset the device to factory settings. To reset the relay, click the Z-Wave™ button twice and hold it for 15 seconds. The LED indicator will flash red during the process and turn solid red for 3 seconds to confirm a successful reset.
The SmartStart QR Code is located on the back of the relay, next to the Z-Wave Plus logo.
