Page 27: Important If you have a Z-Wave network, you must reset the Z-Wave network before resetting your device to factory default. See Reset the Z-Wave network on page 23. Reset to factory default should be used with caution. A reset to factory default resets all settings, including the IP address, to the factory default values. To reset the product to the factory default settings: 1. Disconnect power from the product. 2. Press and hold the control button while reconnecting power. See Product overview on page 31. 3. Keep the control button pressed for 15–30 seconds until the status LED indicator flashes amber. 4. Release the control button. The process is complete when the status LED indicator turns green. The product has been reset to the factory default settings. If no DHCP server is available on the network, the default IP address is 192.168.0.90. Page 23: Important • This procedure removes all Z-Wave devices from the product. • After resetting the Z-Wave network, you also need to either remove each Z-Wave device or reset it to factory default before you can add it to any network again. • Use this procedure only when the network primary controller is missing or otherwise inoperable. 1. Go to System > Z-Wave. 2. Go to Device management and click ["icon"]. 3. Select Reset network in the drop-down menu.

N.A.

N.A.

1. Go to System > Z-Wave. 2. Go to SmartStart and click ["icon"] Add device information. 3. Type the device specific key and any optional information. 4. Click OK.
