Network Module Setting : This setting becomes available through the Main Menu and allows the lock to connect with Controllers. Add(Include) : Master PIN -> ‘R’ -> ‘9’ -> ‘#’ -> ‘1’ -> ‘#’

Network Module Setting : This setting becomes available through the Main Menu and allows the lock to connect with Controllers. Remove(Exclude) : Master PIN -> ‘R’ -> ‘9’ -> ‘#’ -> ‘3’ -> ‘#’ -> Master Pin-> ‘#’

When lock is reset to factory defaults all user codes (including the master code*) are deleted and all programming features are reset to original default setting (see below). (Note# Please use this procedure only when the network’s primary controller is missing or otherwise inoperable.) 1. Remove the battery cover and batteries. 2. Remove the interior escutcheon to access the reset pads. 3. The reset pads are located on bottom of the PCB board. 4. While pressing the reset pads with tweezer, reinstall batteries and release reset pads with tweezer. 5. Replace battery cover. Upon reset, the Master code creation is the only option available and must be performed prior to any other programming of the lock

- QR code location a. 1ea on manual b. 2ea in polybag c. 1ea on side of external body - if prompted, scan QR code
