Alfred
Digital Mortise Door Lock
ML2
Lock DT
HW: 03 FW: 01.01:01.02
EFR32ZG23A
7.18.4
0x0465 (1125)
0x0103 (259)
0x0003 (3)
ZC14-24070459
2024-07-29 13:47:18
N/A
Enhanced End Node 232
Listening Sleeping End Node
Yes
Z-Wave® Controlled mortise Door Lock with key pad and fingerprint scanner.
1 - Configure volume level
Configure volume levelSize: 1 byte
Default: 2
Minimum: 0
Maximum: 2
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | silent |
| 1 | 1 | Low volume |
| 2 | 2 | High volume |
2 - Configure led
Enable/disable ledSize: 1 byte
Default: 1
Minimum: 0
Maximum: 1
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | OFF |
| 1 | 1 | ON (blink) |
3 - Timed battery report
Configure timed battery reportSize: 2 bytes
Default: 1440
Minimum: 0
Maximum: 14400
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Disable timed battery report |
| 1 | 14400 | Enable timed battery report and sets how often battery is reported in minutes. |
4 - Association Group 2 Settings
Configure the Basic Set valueSize: 1 byte
Default: 1
Minimum: 0
Maximum: 6
Possible values
| From | To | Desription |
|---|---|---|
| 0 | 0 | Disable completely. |
| 1 | 1 | Unlocked Status sends Basic SET OxFF, Locked Status sends Basic SET Ox00. |
| 2 | 2 | Unlocked Status sends Basic SET 0x00, Locked Status sends Basic Set OxFF. |
| 3 | 3 | Sends only Basic SET OxFF when Unlocked Status happens. |
| 4 | 4 | Sends only Basic SET 0x00 when Locked Status happens. |
| 5 | 5 | Sends only Basic SET 0x00 when Unlocked Status happens. |
| 6 | 6 | Sends only Basic SET OxFF when Locked Status happens. |
1. Enter master mode(input ** + Master PIN Code + √) 2. Input "8" to enter "Network settings" 3. Input "1" to enter "Include mode"
1. Enter master mode(input ** + Master PIN Code + √ ) 2. Input "8" to enter "Network settings" 3. Input "2" to enter "Exclusion mode"
1. Operations on lock 1) Open the door and keep the lock in "unlock" status. 2) Open battery box and find the reset button. 3) Use a sharp thing to press and hold the reset button 4) Keep holding the reset button and remove the battery from battery box then replace it. 5) Keep holding the reset button down until you hear the lock beep (Can take up to 10 seconds). 2. Please use this procedure only when the network primary controller is missing or otherwise inoperable.
You may find the DSK on individual package of each product.
| Type | Value(s) |
|---|
| Group | Type |
|---|---|
| Access Control |
|
| Home Security | Cover status: Tampering, product cover removed |
