To add the device to the Z-Wave network manually: 1. Power the device. If the device isn''t added to the Z-Wave network, the device LED indicator glows red. 2. Set the main controller in the (Security/non-Security) add mode (for more information, see the controller manual). 3. Quickly, click the PROG button on the device three times. Alternatively, click quickly S1 or S2 three times. 4. If you''re adding the device in the Security S2 Authenticated mode, input the PIN Code, which is labelled on the device. The PIN Code is also an underlined part of the device specific key (DSK) labelled at the bottom of the box. 5. Wait for the LED indicator to blink yellow. 6. Successful adding is confirmed by the Z-Wave controller message and the device LED indicator: Green – successful (non-secure, S0, S2 non-authenticated) Magenta – successful (Security S2 Authenticated) Red – not successful

To remove the device from the Z-Wave network: 1. Make sure the device is powered. 2. Set the main controller in the remove mode (for more information, see the controller manual). 3. Quickly, click the PROG button three times. Alternatively, click quickly S1 or S2 three times within 10 minutes of powering up the device. 4. Wait for the removing process to end. 5. Successful removing is confirmed by the Z-Wave controller message. 6. The device LED indicator glows red.

Reset procedure allows to restore the device back to its factory settings, which means all information about the Z-Wave controller and user configuration will be deleted. 1. Switch off the mains voltage (disable the fuse). 2. Remove the device from the wall switch box. 3. Switch on the mains voltage. 4. Press and hold the PROG button to enter the menu. 5. Wait for the LED indicator to glow yellow. 6. Quickly release and click the PROG button again. 7. During the factory reset, the LED indicator will blink yellow. 8. After few seconds the device will be restarted, which is signal led with the red LED indicator colour.

If you''re adding the device in the Security S2 Authenticated mode, input the PIN Code, which is labelled on the device. The PIN Code is also an underlined part of the device specific key (DSK) labelled at the bottom of the box.
